Titanium Target Sputtering

Grade：GR1/Gr2/GR5 (TI 6AL 4V Eli)
Origin：baoji city Shaanxi Province China
Shape：Round target / plate target / tube target
Standard：ASTM F67, ASTM F136/ISO 13458
Size：1.Diameter 98mm
Height 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm
2. Customized is available

Titanium target sputtering refers to a sputtering source that can sputter various functional thin films on a substrate (glass, PET, etc.) under appropriate process conditions through a magnetron sputtering, multi-arc ion plating, or other coating system.

Titanium target sputtering PVD vacuum coating target
Item	Purity	Density	Coating color	Shape	Standard size	Application
Titanium Aluminum(TiAl) Alloy target	2N8-4N	3.6-4.2	Rose gold/coffee/champagne gold	cylinder/planar	(D)70/100*(H)100-2000mm	PVD decorative coating &hard coating
Pure chrome (Cr)target	2N7-4N	7.19	gun grey/black	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Titanium(Ti) target	2N8-4N	4.51	gold/rose gold/blue/rainbow/light black/gun grey	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Zirconium(Zr) target	2N5-4N	6.5	light gold	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Aluminium(Al) target	4N-5N	2.7	silver	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Nickel (Ni) target	3N-4N	8.9	nickel	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Niobium (Nb) target	3N	8.57	white	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Tantalum(Ta) target	3N5	16.4	black/pure	cylinder/planar	(D)70/100*(H)100-2000mm
Pure Molybdenum (Mo) target	3N5	10.2	black	cylinder/planar	(D)70/100*(H)100-2000mm
Remarks: Size can be customizaed according to specical requirements

Established in 2014, Baoji Chenyuan Metal Material Co., Ltd Industrial is one of the largest hot sale 3D PRINT Titanium Powder, 3D PRINT Titanium Consumables ,titanium Ingots, titanium forgings, titanium Bars, titanium Sheets/Plates,titanium target sputtering and made titanium machine parts . manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.

Welcome to send an inquiry to mira@xjcmetal.com at any time if you need.
